crusde_api.h File Reference

#include "constants.h"
#include "config.h"
#include "stdarg.h"

Include dependency graph for crusde_api.h:

This graph shows which files directly or indirectly include this file:

Defines
#define	boolean int
#define	true 1
#define	false 0
#define	NOT_TIME_DEPENDENT false
#define	TIME_DEPENDENT true
Enumerations
enum	PluginCategory { LOAD_PLUGIN = 0, KERNEL_PLUGIN = 1, GREEN_PLUGIN = 2, DATAOUT_PLUGIN = 3, POSTPROCESS_PLUGIN = 4, LOADHISTORY_PLUGIN = 5, CRUSTALDECAY_PLUGIN = 6 }
enum	FieldName { X_FIELD = 0, Y_FIELD = 1, Z_FIELD = 2, ADD_FIELD = 3 }
enum	ExitCode { ERROR_MSG = -1, NOERROR = 0 }
Functions
void	crusde_error (const char *format,...)
	Prints error message to stderr, exists CrusDe with code ERROR_MSG.
void	crusde_debug (const char *format,...)
	Prints debug messages to stderr if compiled with -DDEBUG.
void	crusde_warning (const char *format,...)
	Prints warning message to stderr.
void	crusde_info (const char *format,...)
	Prints information message to stdout.
double *	crusde_register_param_double (const char *param_name, PluginCategory)
	Register double parameter that is required by a plug-in.
double *	crusde_register_optional_param_double (const char *param_name, PluginCategory, double)
	Register optional double parameter for a plug-in.
char **	crusde_register_param_string (const char *param_name, PluginCategory)
	Register string parameter that is required by a plug-in, e.g. if you need a file name.
char **	crusde_register_optional_param_string (const char param_name, PluginCategory, char )
	Register optional string parameter for a plug-in, e.g. if you want to allow for an optional output file.
void	crusde_register_output_field (int *position, FieldName)
	Request space in the output array. This allocates necessary memory for your results.
int	crusde_get_size_x ()
	X, Easting dimension of the spatial grid.
int	crusde_get_size_y ()
	Y, Northing dimension of the spatial grid.
int	crusde_get_size_t ()
	Basically the number of time steps to be modeled.
int	crusde_get_gridsize ()
	get size of spatial grid defined in XML model file
int	crusde_get_min_x ()
	Minimum X value, i.e. Western limit of the region of interest.
int	crusde_get_min_y ()
	Minimum Y value, i.e. Southern limit of the region of interest.
int	crusde_get_dimensions ()
	total number of output dimensions
int	crusde_get_displacement_dimensions ()
	displacement dimensions that are modeled, e.g. X, Z or X,Y or Z only
int	crusde_model_time ()
	return current model time
int	crusde_get_timesteps ()
	returns total number of time steps
int	crusde_model_step ()
	return current model step, i.e. number of iterations done (temporally)
int	crusde_stepsize ()
	Time increment with each model step.
int	crusde_get_x_index ()
	Index of X-displacement value in output array.
int	crusde_get_y_index ()
	Index of y-displacement value in output array.
int	crusde_get_z_index ()
	Index of Z-displacement value in output array.
const char *	crusde_get_observation_file ()
const char *	crusde_get_out_file ()
	Returns the name of the result file as defined in the XML model file.
int	crusde_get_green_at (double **res, int x, int y)
	Get value of Green's function at a specific coordinate.
double	crusde_get_load_at (int x, int y)
	Get value of Load function at Point p(x,y).
double	crusde_get_load_history_at (int t)
	Get value of Load History function at time t.
double	crusde_get_crustal_decay_at (int t)
	Get value of Crustal Decay function at time t.
void	crusde_set_result (double **)
	hand model result to Simulation Core
double **	crusde_get_result ()
	retrieve model result from Simulation Core
void	crusde_set_quadrant (int)
	Set Coordinate system quadrant (1-4) that we're currently working in.
int	crusde_get_quadrant ()
	Get Coordinate system quadrant (1-4) that we're currently working in.
void	crusde_exit (ExitCode code)
	Gracefully terminates CrusDe, i.e. shuts down the whole system before exiting with ExitCode 'code'.
int	crusde_get_current_load_component ()
	Returns the current load function id such that the load plugins can set the parameter pointers to the respective array index.
void	crusde_set_current_load_component (int)
	Update currend load component id.
int	crusde_get_number_of_loads ()
	Get total number of load functions defined in the XML model file.
void	crusde_set_operator_space (int, int)
	Operator can set the spatial dimensions it works on.
void	crusde_get_operator_space (int , int )
	Read model dimensions, i.e. Region of Interest.
boolean	crusde_crustal_decay_given ()
	Has a crustal decay function been defined?
boolean	crusde_load_history_given ()
	Has a load history function been defined?
green_exec_function	crusde_request_green_plugin (char *plugin)
	A Green's function plugin can request the run time function of another Green's function plug-in to reuse its functionality.
load_exec_function	crusde_request_load_plugin (char *plugin)
	A Load function plugin can request the run time function of another Load function plug-in to reuse its functionality.
run_function	crusde_request_kernel_plugin (char *plugin)
	An Operator/Kernel plugin can request the run time function of another operator/kernel plug-in to reuse its functionality.
run_function	crusde_request_postprocessor_plugin (char *plugin)
	A Postprocessor plugin can request the run time function of another Postprocessor plug-in to reuse its functionality.
loadhistory_exec_function	crusde_request_loadhistory_plugin (char *plugin)
	A Load history function plugin can request the run time function of another Load history function plug-in to reuse its functionality.
crustaldecay_exec_function	crusde_request_crustaldecay_plugin (char *plugin)
	A Crustal decay function plugin can request the run time function of another Crustal decay function plug-in to reuse its functionality.

Define Documentation

#define boolean int

#define false 0

#define NOT_TIME_DEPENDENT false

#define TIME_DEPENDENT true

#define true 1

Enumeration Type Documentation

enum ExitCode

Enumerator:

ERROR_MSG	error message printed, aborting program
NOERROR	no error occured

enum FieldName

Enumerator:

X_FIELD
Y_FIELD
Z_FIELD
ADD_FIELD

enum PluginCategory

Enumerator:

LOAD_PLUGIN
KERNEL_PLUGIN
GREEN_PLUGIN
DATAOUT_PLUGIN
POSTPROCESS_PLUGIN
LOADHISTORY_PLUGIN
CRUSTALDECAY_PLUGIN

Function Documentation

boolean crusde_crustal_decay_given ( )

Has a crustal decay function been defined?

References LoadFunction::crustalDecayGiven(), SimulationCore::instance(), and SimulationCore::loadFunction().

Referenced by run().

void crusde_debug	(	const char *	format,
			...
	)

Prints debug messages to stderr if compiled with -DDEBUG.

This function prints a debug message to stderr if CrusDe was compiled with flag -DDEBUG; else nothing is printed; hence debug statements can stay with the code. It is strongly recommended to use this function that works exactly like printf, instead of printf. This way the output of CrusDe is not cluttered with tests and development messages.

Parameters:

	format	A formatted string following the sprintf conventions
	...	Elipsis containing the values to be plugged into the format string

Returns:: void

See also:: crusde_warning(), crusde_info(), crusde_error()

Referenced by crusde_register_optional_param_double(), crusde_register_optional_param_string(), crusde_register_param_double(), crusde_register_param_string(), ExperimentManager::ExperimentManager(), InputHandler::getAttributeValue(), InputHandler::getAttributeValueByName(), InputHandler::getGreenJobMap(), InputHandler::getLoadFunctionList(), init(), InputHandler::initParamsFromDOM(), Plugin::load(), LoadPlugin::load(), LoadHistoryPlugin::load(), GreenPlugin::load(), DataOutPlugin::load(), CrustalDecayPlugin::load(), Plugin::Plugin(), PluginManager::PluginManager(), read_alma_output(), InputHandler::readCommandline(), XMLHandler::readXML(), run(), DataOutPlugin::setModelData(), Plugin::unload(), XMLHandler::writeXML(), XMLHandler::XMLHandler(), CrustalDecayPlugin::~CrustalDecayPlugin(), DataOutPlugin::~DataOutPlugin(), GreenPlugin::~GreenPlugin(), InputHandler::~InputHandler(), LoadHistoryPlugin::~LoadHistoryPlugin(), LoadPlugin::~LoadPlugin(), Plugin::~Plugin(), XMLCore::~XMLCore(), and XMLHandler::~XMLHandler().

void crusde_error	(	const char *	format,
			...
	)

Prints error message to stderr, exists CrusDe with code ERROR_MSG.

This function prints an error message to stderr. It works exactly like printf, hence complex message printing is possible. The simulation run will be terminated by calling crusde_exist with the error code ERROR_MSG.

Parameters:

	format	A formatted string following the sprintf conventions
	...	Elipsis containing the values to be plugged into the format string

Returns:: void

See also:: crusde_warning(), crusde_info(), crusde_debug(), crusde_exit()

References crusde_exit(), and ERROR_MSG.

Referenced by PluginManager::deleteEntry(), InputHandler::getGreenJobMap(), init(), InputHandler::init(), InputHandler::initParamsFromDOM(), SimulationCore::installPlugin(), SimulationCore::instance(), main(), ParamWrapper::newDouble(), ParamWrapper::newString(), InputHandler::readCommandline(), XMLHandler::readXML(), SimulationCore::registerParam(), and ParamWrapper::setValue().

void crusde_exit ( ExitCode code )

Gracefully terminates CrusDe, i.e. shuts down the whole system before exiting with ExitCode 'code'.

See also:: ExitCode

References SimulationCore::instance(), and SimulationCore::terminate().

Referenced by crusde_error(), init(), and read_alma_output().

double crusde_get_crustal_decay_at ( int t )

Get value of Crustal Decay function at time t.

Parameters:

t

Time for which the crustal decay function value is sought.

Returns:: double Crustal decay at time t.

References LoadFunction::getCrustalDecayValueAt(), SimulationCore::instance(), and SimulationCore::loadFunction().

Referenced by run().

int crusde_get_current_load_component ( )

Returns the current load function id such that the load plugins can set the parameter pointers to the respective array index.

See also:: crusde_set_current_load_component(), crusde_get_number_of_load_components()

References SimulationCore::getLoadFunctionComponent(), and SimulationCore::instance().

Referenced by clear(), get_value_at(), init(), register_parameter(), and set_history_function().

int crusde_get_dimensions ( )

total number of output dimensions

See also:: crusde_get_displacement_dimensions()

References SimulationCore::getDimensions(), and SimulationCore::instance().

Referenced by init(), and run().

int crusde_get_displacement_dimensions ( )

displacement dimensions that are modeled, e.g. X, Z or X,Y or Z only

See also:: crusde_get_dimensions()

References SimulationCore::displacementDimensions(), and SimulationCore::instance().

Referenced by init().

int crusde_get_green_at	(	double **	result,
		int	x,
		int	y
	)

Get value of Green's function at a specific coordinate.

Parameters:

	result	pointer to array to which the Green's function (possibly for 3 spatial dimensions) is written
	x,y	spatial coordinates for which the Green's function is requested

Returns:: Error code

References GreensFunction::getValueArrayAt(), SimulationCore::greensFunction(), and SimulationCore::instance().

Referenced by run().

int crusde_get_gridsize ( )

get size of spatial grid defined in XML model file

References SimulationCore::gridSize(), and SimulationCore::instance().

Referenced by get_value_at(), and init().

double crusde_get_load_at	(	int	x,
		int	y
	)

Get value of Load function at Point p(x,y).

Parameters:

x,y

X,Y coordinates of grid point at which the load value is sought.

Returns:: double Load at Point p(x,y).

References LoadFunction::getValueAt(), SimulationCore::instance(), and SimulationCore::loadFunction().

Referenced by run().

double crusde_get_load_history_at ( int t )

Get value of Load History function at time t.

Parameters:

t

Time for which the load history value is sought.

Returns:: double Load History value at time t.

References LoadFunction::getHistoryValueAt(), SimulationCore::instance(), and SimulationCore::loadFunction().

Referenced by run().

int crusde_get_min_x ( )

Minimum X value, i.e. Western limit of the region of interest.

See also:: crusde_get_min_y()

References SimulationCore::instance(), and SimulationCore::minX().

Referenced by get_value_at(), and init().

int crusde_get_min_y ( )

Minimum Y value, i.e. Southern limit of the region of interest.

See also:: crusde_get_min_x()

References SimulationCore::instance(), and SimulationCore::minY().

Referenced by get_value_at(), and init().

int crusde_get_number_of_loads ( )

Get total number of load functions defined in the XML model file.

Returns:: int just what the function suggests

References SimulationCore::getNumberOfLoadComponents(), and SimulationCore::instance().

Referenced by run().

const char* crusde_get_observation_file ( )

void crusde_get_operator_space	(	int *	nx,
		int *	ny
	)

Read model dimensions, i.e. Region of Interest.

Parameters:

	*nx	pointer to memory slot to which the number of fields in X direction is to be written
	*ny	pointer to memory slot to which the number of fields in Y direction is to be written

Returns:: void

See also:: crusde_set_operator_space()

References SimulationCore::getOperatorSpaceX(), SimulationCore::getOperatorSpaceY(), and SimulationCore::instance().

const char* crusde_get_out_file ( )

Returns the name of the result file as defined in the XML model file.

References SimulationCore::instance(), and SimulationCore::outFile().

Referenced by init().

int crusde_get_quadrant ( )

Get Coordinate system quadrant (1-4) that we're currently working in.

See also:: crusde_set_quadrant()

References SimulationCore::getQuadrant(), and SimulationCore::instance().

Referenced by get_value_at().

double** crusde_get_result ( )

retrieve model result from Simulation Core

See also:: crusde_set_result()

References SimulationCore::getModelData(), and SimulationCore::instance().

Referenced by run().

int crusde_get_size_t ( )

Basically the number of time steps to be modeled.

References SimulationCore::instance(), and SimulationCore::sizeT().

Referenced by init().

int crusde_get_size_x ( )

X, Easting dimension of the spatial grid.

See also:: crusde_get_size_y(), crusde_get_size_t()

References SimulationCore::instance(), and SimulationCore::sizeX().

Referenced by init().

int crusde_get_size_y ( )

Y, Northing dimension of the spatial grid.

See also:: crusde_get_size_x(), crusde_get_size_t()

References SimulationCore::instance(), and SimulationCore::sizeY().

Referenced by init().

int crusde_get_timesteps ( )

returns total number of time steps

References SimulationCore::getTimesteps(), and SimulationCore::instance().

Referenced by init().

int crusde_get_x_index ( )

Index of X-displacement value in output array.

References SimulationCore::instance(), and SimulationCore::xIndex().

Referenced by init(), and run().

int crusde_get_y_index ( )

Index of y-displacement value in output array.

References SimulationCore::instance(), and SimulationCore::yIndex().

Referenced by init(), and run().

int crusde_get_z_index ( )

Index of Z-displacement value in output array.

References SimulationCore::instance(), and SimulationCore::zIndex().

Referenced by init(), and run().

void crusde_info	(	const char *	format,
			...
	)

Prints information message to stdout.

This function prints an information message to stdout. It works exactly like printf, hence complex message printing is possible. The simulation run will be continued.

Parameters:

	format	A formatted string following the sprintf conventions
	...	Elipsis containing the values to be plugged into the format string

Returns:: void

See also:: crusde_warning(), crusde_error(), crusde_debug()

References SimulationCore::instance().

Referenced by SimulationCore::addGreenPlugin(), SimulationCore::exec(), InputHandler::getLoadFunctionList(), InputHandler::getPostProcessorNameList(), SimulationCore::init(), init(), main(), InputHandler::readCommandline(), register_output_fields(), Plugin::registerParameter(), and run().

boolean crusde_load_history_given ( )

Has a load history function been defined?

References SimulationCore::instance(), SimulationCore::loadFunction(), and LoadFunction::loadHistoryGiven().

Referenced by run().

int crusde_model_step ( )

return current model step, i.e. number of iterations done (temporally)

References SimulationCore::instance(), and SimulationCore::modelStep().

Referenced by run().

int crusde_model_time ( )

return current model time

References SimulationCore::instance(), and SimulationCore::modelTime().

Referenced by run().

double* crusde_register_optional_param_double	(	const char *	name,
		PluginCategory	category,
		double	default_value
	)

Register optional double parameter for a plug-in.

Use this function if your parameter is optional. Be sure to define sensible Parameter names that convey some context of the actual parameter, e.g., 'E' for Young's modulus or 'g' for gravitational acceleration. Keep in mind that the 'name' is case sensitive.

Parameters:

	name	Name of the parameter (defines how the parameter has to show up in the XML model file)
	category	Elipsis containing the values to be plugged into the format string
	default_value	Obviously the value that this parameter is set to if it's not defined in the input file

Returns:: double* Pointer to the memory slot allocated for the parameter (keep track if you got multiple plug-ins of the same type!)

See also:: PluginCatergory, crusde_register_param_double()

References crusde_debug(), SimulationCore::instance(), ParamWrapper::newDouble(), SimulationCore::registerParam(), and ParamWrapper::setOptional().

char** crusde_register_optional_param_string	(	const char *	name,
		PluginCategory	category,
		char *	default_value
	)

Register optional string parameter for a plug-in, e.g. if you want to allow for an optional output file.

Use this function if your parameter is optional. Be sure to define sensible Parameter names that convey some context of the actual parameter, e.g., 'load_file' for a file that defines the surface load, or 'result' for the result file. Keep in mind that the 'name' is case sensitive.

Parameters:

	name	Name of the parameter (defines how the parameter has to show up in the XML model file)
	category	Elipsis containing the values to be plugged into the format string
	default_value	Obviously the value that this parameter is set to if it's not defined in the input file

Returns:: double* Pointer to the memory slot allocated for the parameter (keep track if you got multiple plug-ins of the same type!)

See also:: PluginCatergory, crusde_register_param_double()

References crusde_debug(), SimulationCore::instance(), ParamWrapper::newString(), SimulationCore::registerParam(), and ParamWrapper::setOptional().

Referenced by register_parameter().

void crusde_register_output_field	(	int *	position,
		FieldName	field
	)

Request space in the output array. This allocates necessary memory for your results.

CrusDe manages your memory this way and also assures that your results make it into the output data at the specified position. E.g., if the 'position' you get from CrusDe is 5 you will find your results in column 5 of an ascii table or in the 5th index of a netCDF file.

Parameters:

	position	pointer to memory slot to which the output array position will be written. has to show up in the XML model file)
	field	claim one of the standard fields (e.g. deformation in X/Y/Z direction; or an additional, user defined field)

Returns:: void

See also:: FieldName

References SimulationCore::instance(), and SimulationCore::registerOutputField().

Referenced by register_output_fields().

double* crusde_register_param_double	(	const char *	name,
		PluginCategory	category
	)

Register double parameter that is required by a plug-in.

Use this function if your parameter is not optional. Be sure to define sensible Parameter names that convey some context of the actual parameter, e.g., 'E' for Young's modulus or 'g' for gravitational acceleration. Keep in mind that the 'name' is case sensitive.

Parameters:

	name	Name of the parameter (defines how the parameter has to show up in the XML model file)
	category	Elipsis containing the values to be plugged into the format string

Returns:: double* Pointer to the memory slot allocated for the parameter (keep track if you got multiple plug-ins of the same type!)

See also:: PluginCatergory, crusde_register_optional_param_double()

References crusde_debug(), SimulationCore::instance(), ParamWrapper::newDouble(), SimulationCore::registerParam(), and ParamWrapper::setOptional().

Referenced by register_parameter().

char** crusde_register_param_string	(	const char *	name,
		PluginCategory	category
	)

Register string parameter that is required by a plug-in, e.g. if you need a file name.

Use this function if your parameter is optional. Be sure to define sensible Parameter names that convey some context of the actual parameter, e.g., 'load_file' for a file that defines the surface load, or 'result' for the result file. Keep in mind that the 'name' is case sensitive.

Parameters:

	name	Name of the parameter (defines how the parameter has to show up in the XML model file)
	category	Elipsis containing the values to be plugged into the format string

Returns:: char** Pointer to the memory slot allocated for the parameter (pointer to a char array (keep track if you got multiple plug-ins of the same type!)

See also:: PluginCatergory, crusde_register_optional_param_string()

References crusde_debug(), SimulationCore::instance(), ParamWrapper::newString(), SimulationCore::registerParam(), and ParamWrapper::setOptional().

Referenced by register_parameter().

crustaldecay_exec_function crusde_request_crustaldecay_plugin ( char * plugin )

A Crustal decay function plugin can request the run time function of another Crustal decay function plug-in to reuse its functionality.

Parameters:

plugin

Name of the Crustal Decay function to be re-used as defined in Plugin Manager, e.g. "exponential"

Returns:: crustaldecay_exec_function Funtion pointer to the 'run()' function of a Crustal decay function, i.e. get_crustal_decay_at ...

See also:: crusde_request_green_plugin(), crusde_request_kernel_plugin(), crusde_request_postprocessor_plugin(), crusde_request_loadhistory_plugin(), crusde_request_load_plugin(), PluginCategory

References SimulationCore::abort(), SimulationCore::addCrustalDecayPlugin(), and SimulationCore::instance().

green_exec_function crusde_request_green_plugin ( char * plugin )

A Green's function plugin can request the run time function of another Green's function plug-in to reuse its functionality.

This function implements the concept of plug-in reuse. By allowing access to the run-function of a plugin of the same category, a new plugin can build on existing functionality. Instead of having to reimplement fundamental behavior, CrusDe allows to request an executing function and loads the respective plugin in the background. The reusing plugin does not have to worry about having to remember all the correct parameters for the respective plug-in. CrusDe assures that the input file is being checked for those values and that the values make it into the plugin registry and to the plugin.

Parameters:

plugin

Name of the Green's function to be re-used as defined in Plugin Manager, e.g. "elastic halfspace (pinel)"

Returns:: green_exec_function Function pointer to the 'run()' function of a Green's function, i.e. get_green_at ...

See also:: crusde_request_load_plugin(), crusde_request_kernel_plugin(), crusde_request_postprocessor_plugin(), crusde_request_loadhistory_plugin(), crusde_request_crustaldecay_plugin(), PluginCategory

References SimulationCore::abort(), SimulationCore::addGreenPlugin(), and SimulationCore::instance().

Referenced by request_plugins().

run_function crusde_request_kernel_plugin ( char * plugin )

An Operator/Kernel plugin can request the run time function of another operator/kernel plug-in to reuse its functionality.

Parameters:

plugin

Name of the operator to be re-used as defined in Plugin Manager, e.g. "fast 2d convolution"

Returns:: run_function Function pointer to the 'run()' function of an operator.

See also:: crusde_request_green_plugin(), crusde_request_load_plugin(), crusde_request_postprocessor_plugin(), crusde_request_loadhistory_plugin(), crusde_request_crustaldecay_plugin(), PluginCategory

References SimulationCore::abort(), SimulationCore::addKernelPlugin(), and SimulationCore::instance().

Referenced by request_plugins().

load_exec_function crusde_request_load_plugin ( char * plugin )

A Load function plugin can request the run time function of another Load function plug-in to reuse its functionality.

Parameters:

plugin

Name of the Load function to be re-used as defined in Plugin Manager, e.g. "irregular load"

Returns:: load_exec_function Function pointer to the 'run()' function of a Load function, i.e. get_load_at ...

See also:: crusde_request_green_plugin(), crusde_request_kernel_plugin(), crusde_request_postprocessor_plugin(), crusde_request_loadhistory_plugin(), crusde_request_crustaldecay_plugin(), PluginCategory

References SimulationCore::abort(), SimulationCore::addLoadPlugin(), and SimulationCore::instance().

loadhistory_exec_function crusde_request_loadhistory_plugin ( char * plugin )

A Load history function plugin can request the run time function of another Load history function plug-in to reuse its functionality.

Parameters:

plugin

Name of the Load history function to be re-used as defined in Plugin Manager, e.g. "sinusoidal"

Returns:: loadhistory_exec_function Function pointer to the 'run()' function of a Load history function, i.e. get_loadhistory_at ...

See also:: crusde_request_green_plugin(), crusde_request_kernel_plugin(), crusde_request_postprocessor_plugin(), crusde_request_load_plugin(), crusde_request_crustaldecay_plugin(), PluginCategory

References SimulationCore::abort(), SimulationCore::addLoadHistoryPlugin(), and SimulationCore::instance().

run_function crusde_request_postprocessor_plugin ( char * plugin )

A Postprocessor plugin can request the run time function of another Postprocessor plug-in to reuse its functionality.

Parameters:

plugin

Name of the postprocessor to be re-used as defined in Plugin Manager

Returns:: run_function Function pointer to the 'run()' function of a Postprocessor function.

See also:: crusde_request_green_plugin(), crusde_request_load_plugin(), crusde_request_kernel_plugin(), crusde_request_loadhistory_plugin(), crusde_request_crustaldecay_plugin(), PluginCategory

References SimulationCore::abort(), SimulationCore::addPostprocessorPlugin(), and SimulationCore::instance().

void crusde_set_current_load_component ( int id )

Update currend load component id.

See also:: crusde_get_current_load_component(), crusde_get_number_of_load_components()

References SimulationCore::instance(), and SimulationCore::setLoadFunctionComponent().

Referenced by run().

void crusde_set_operator_space	(	int	nx,
		int	ny
	)

Operator can set the spatial dimensions it works on.

This is useful if somebody wants to temporarily store and ACCESS spatial results - arrays are stored linearily.

Parameters:

	nx	Number of fields in the X direction, i.e., easting
	ny	Number of fields in the Y direction, i.e., northing

Returns:: void

See also:: crusde_get_operator_space()

References SimulationCore::instance(), and SimulationCore::setOperatorSpace().

Referenced by init().

void crusde_set_quadrant ( int q )

Set Coordinate system quadrant (1-4) that we're currently working in.

CrusDe is inherently cartesian in nature, if a Green's function, for example, operates in a Cyllindrical world, it might be necessary to know which quadrant we're in to correctly determine the direction cosine.

See also:: crusde_get_quadrant()

References SimulationCore::instance(), and SimulationCore::setQuadrant().

Referenced by run().

void crusde_set_result ( double ** result )

hand model result to Simulation Core

See also:: crusde_get_result()

References SimulationCore::instance(), and SimulationCore::setModelData().

Referenced by run().

int crusde_stepsize ( )

Time increment with each model step.

References SimulationCore::instance(), and SimulationCore::stepSize().

Referenced by init().

void crusde_warning	(	const char *	format,
			...
	)

Prints warning message to stderr.

This function prints a warning message to stderr. It works exactly like printf, hence complex message printing is possible. The simulation run will be continued.

Parameters:

	format	A formatted string following the sprintf conventions
	...	Elipsis containing the values to be plugged into the format string

Returns:: void

See also:: crusde_error(), crusde_info(), crusde_debug()

Referenced by ExperimentManager::addEntry(), PluginManager::addToDB(), ExperimentManager::deleteEntry(), Plugin::getCategory(), InputHandler::getLoadFunctionList(), SimulationCore::getRegisteredParameters(), init(), Plugin::init(), InputHandler::init(), InputHandler::initParamsFromDOM(), SimulationCore::installPlugin(), InputHandler::jobExists(), GreensFunction::load(), read_alma_output(), XMLHandler::readXML(), SimulationCore::registerOutputField(), Plugin::registerParameter(), run(), XMLCore::XMLCore(), XMLCore::~XMLCore(), and XMLHandler::~XMLHandler().

crusde_api.h File Reference

Defines

Enumerations

Functions

Define Documentation

Enumeration Type Documentation

Function Documentation
